| Perm ID | Sage ID | JSS ID | Unit | Location | Early Equip. |
Final Equip. |
Oper. Date |
Inact. Date |
Notes |
|---|---|---|---|---|---|---|---|---|---|
| TM-196 | Z-196 | 693 | Dauphin Island AFS, AL | FPS-20; FPS-6A (2); FPS-7 | FPS-93A; FPS-6 * | Jan-59 | Sep-70 * | * Re-opened in 1972 as part of the Southern Air Defense System. | |
| TM-196A / M-126A | Z-126A | New Orleans, LA | FPS-14 | FPS-18 | Oct-57 | 1 July 1970 | Gap-Filler Annex. The radar site was located at Camp Leroy Johnson (next to Lake Pontchartrain). | ||
| TM-196B | Z-196B | Gulfport, MS | FPS-18 | Aug-61 | 01-Jul-70 | Gap-Filler Annex. Site was just east of the airport, on 47th Street, between Adams Ave. and Chamberlain Ave., per USACE FUDS report. |
Current Use: Dauphin Island Sea Lab. [See also Dauphin Island AFS, AL, 635th Radar Squadron (Z-249); and Dauphin Island AFS, AL, OLAG 630th Radar Squadron (Z-249).]
